HLAE Hygienic Series Planetary Gearboxes

The HLAE Hygienic series of planetary gearboxes is the ideal gearbox for application in environments where excellent hygiene is of great importance. Examples include the pharmaceutical industry, food industry and other applications where moisture and dirt play a role. Because of the materials used and the high-quality design, the HLAE excels in both performance and hygiene requirements.

The stainless steel delay box that meets all requirements

The Neugart HLAE planetary gearbox was specially developed to meet the stringent requirements of the pharmaceutical and food industries day in and day out. The materials used and the innovative design contribute to making this gearbox the ideal partner for environments that need to be kept clean and require regular proper cleaning. For example, the HLAE Hygienic Series planetary gearbox is completely designed to prevent the accumulation of dirt and residue. As a result, the gearbox helps prevent any infections resulting from such dirt accumulation. Also, the gearbox is waterproof and can be cleaned with chemical cleaners.

The HLAE is unique: It is the world’s first planetary gearbox in a certified hygienic design – flexible without a radial bolt, powerful and yet easy and quick to clean. It is specially designed for applications in sensitive sectors such as pharmaceuticals, cosmetics and food industry.

The HLAE stainless steel planetary gearbox is the ultimate in hygienic design and thus can be used for the most critical hygienic application. Available in three different construction sizes, the HLAE delivers optimum performance in the best possible protection class.

Specific features of the HLAE series

3-A RPSCQC certified
FDA certified materials
NSF H1 lubricant
No radial bolts
Protection class	IP69K
Nominal output torque	15 – 171 Nm
Backlash	7 – 12 arcmin
Radial force	450 – 14,500 N
Axial force	550 – 2,500 N
Protection class	IP69K

Neugart-HLAE-Hygienic-design

Find the right gearbox with an expert from Caldic Techniek

At Caldic Techniek we have years of experience applying gearboxes in a multitude of challenging environments. As absolute experts in the field of Neugart’s reliable and high-quality gearboxes, we are happy to help you find the right gearbox for your application. Based on our knowledge and experience, we will be happy to tell you more about the possibilities that the various planetary gearboxes have to offer. Together we will find the ideal solution for your project. Please feel free to contact us so that we can share our knowledge and insights with you.
